Safety & Interlock Sheet

This Safety and Interlock Sheet is a cryogenic digital download designed to help nitrogen plant and ASU operators understand critical safety logics, interlock behavior, and trip conditions. It summarizes key protections built into the cold box, purification system, compressor, expander, and high-pressure circuits—enabling teams to recognize why a trip occurred, when a bypass is unsafe, and how to operate the plant within safe limits during commissioning and steady operation.

What This Safety and Interlock Sheet Covers

• Summary of essential cryogenic interlocks and protection logics

• Trip conditions linked to pressure, temperature, purity, and analyzer failures

• Cold box protection: anti-freeze, anti-flooding, ΔT and ΔP interlocks

• Purifier interlocks: switching logic, heater safety, regeneration permissives

• Compressor and expander safety logic overview

• Emergency shutdown (ESD) links and restart permissives

• Operator notes for safe handling and common hazards

• “Do-not-bypass” warnings and engineering rationale

Who This Safety and Interlock Sheet Is For

• Cryogenic nitrogen plant operators

• ASU commissioning engineers

• Safety & instrumentation teams

• Troubleshooting and start-up supervisors

• EPC commissioning contractors

When To Use This Sheet

• During familiarization before plant start-up

• During troubleshooting after a trip or shutdown

• For operator training and shift handover

• Before deciding whether an interlock can be overridden (most must not be)

• For compliance and safety audits
