The Cold Box Start Up Flow Sequence is a cryogenic digital download designed to help ASU and nitrogen plant teams execute a controlled, step-by-step start-up of the cold box. This guide provides a structured flow sequence, recommended temperature and pressure checkpoints, ΔT/ΔP interpretation during cool-down, and early-warning indicators to prevent flooding, freezing, or maldistribution. It is ideal for commissioning, start-up training, and maintaining start-up discipline across shifts.

What This Cold Box Start Up Flow Sequence Covers

• Pre-start verification checks before cool-down

• Recommended order of valve movements and flow setpoints

• Safe flow ramp-up sequence for exchangers and columns

• Expected ΔT and ΔP behaviour during initial cool-down

• Warm-end and cold-end stabilization indicators

• Flooding and freezing early-warning patterns

• Key purity and temperature checkpoints

• Operator notes for sequence timing and adjustments

Who This Cold Box Start Up Flow Sequence Is For

• Commissioning engineers

• ASU & nitrogen plant operators

• EPC start-up teams

• Troubleshooting and process support teams

• Shift supervisors and trainees

When To Use This Cold Box Start Up Flow Sequence

• During cold box cool-down

• At plant start-up after shutdown or maintenance

• When restarting after upset recovery

• For operator training and standardization

• When verifying correct start-up procedures across teams

✅ 3. Why This Cold Box Start Up Flow Sequence Helps

• Provides a clear, repeatable sequence for cool-down and start-up

• Reduces start-up instability and prevents freezing/flooding

• Improves operator confidence and consistency

• Supports faster stabilization of ΔT, ΔP, and purity

• Enhances communication between field and control room

• Minimizes risks caused by incorrect flow ramp-up or timing
